1.      DELEM DA52 CNC SYSTEM

2.      SIEMENS OR SCHNEIDER ELECTRONIC ELEMENTS

3.      USA PARKER SEAL

4.      GERMANY REXORTH HYDRAULIC SYSTEM.ELECTRONIC-HYDRAULIC SYNCHRONIZATION PROPORTION VALVE.

5.      GERMANY ECKERLE OR CHINA YONGSHUN

6.      SIEMENS MOTOR or CHINA FAR EAST Motor

7.      CHINA JIANHU CYLINDER HAS CHROMATE TREATMETN

8.      PUNCH AND DIES: T8A

9.      SECTION PUNCH AND DIES AVAIALABE IF THE CLIENT NEEDS SMALL SLIP PUNCH BENDING

10.    BACK-GAUGE: 4 AXIS BACKGAUGE

11.    PIPES : ANTI-RUST PHOSPHORIZATION PIPES WITH BOTH INSIDE AND OUTSIDE ANTI-RUST TREATED

12.    PIPE CONNECTOR: HIGH QUALITY CONNCTOR FROM SHANGHAI COMPANY WITH HIGH QUALTY SEAL INSIDE TO PREVEND THE LEAKAGE OF THE HYDRAULC OIL.

13.    REAR DOOR WITH OPEN-DOOR POWER-OFF FUNCTION FOR SECURITY

14.    BOTH ENTRANCE AND EXIST OF THE HYDRAULIC OIL TANK, FILTER IS EQUIPPED.

15.    MECHANICAL PUNCH RELEASE CLAMP

16.    LIGH CURTIAIN 800MM

17.    STANDARD AXIS: Y1/Y2/X+V AXIS (3+1 AXIS)

18.    GRATING RULER: ITALY GIVI

19.    SEVER MOTO: CHINA ESTUN

n  HYDRAULIC SYSTEM

1.         USE GERMANY REXROTH PROPORTIONAL SERVO VALVE AND REACH HIGH SYNCHRONIZATION CONTROL PRECISION

2.         MACHNE CAN WORK CONTINUOUSLY UNDER RATED BURDEN ,HYDRAULIC SYSTEM WITHOUT LEAKAGE ,STABLE AND HIGH PRECISION

n   ELECTRICAL CONTROL SYSTEM

1.         Electrical Cabinet under the standard of IP65, Electronic components under international CE Standard, safe and reliable, strong anti interference capability.

2.     Movable hands safety pedal switch with the emergency stop function.

n   SYNCHRONIZATION CONTROL OF THE MAIN CYLINDER

Two Main Cylinder's movement and position are controlled by Y1 and Y2 Axis,Y1 and Y2 are two separately parameter of CNC Control system. Tow sides of the machine configure two imported grating ruler to calculate the real distance between the ram and working table. Grating rulers are equipped a small rack in the connection of the working table to eliminate the influence of the ram location caused by the upright column deformation.

When the slider is moving, the position digital details will feedback into CNC System, so the Servo valve control signal S1 and S2 will be calculated and output and control the output flow of the two servo valve to make sure the left and right main cylinder will working synchronization from beginning to end and will guarantee the high speed and position precision of the slider when working

n   THE V AXIS (MOTOR –CROWNING)

DELEM DNC 60 SYSTEM BOTH IN TORSION BAR AND SYNCHRONZIAITON PRESS BKAKE , CAN CONTROL AND CALCULATE AUTOMATICAL COMPENSATION FOR WORKING TABLE. WE RECOMMEND THIS IF THE WORKING TABLE IS MORE THAN 3000MM.

CNC System V Axis control cylinder to reach the compensation. The CNC system can automatically reach the working table deflection compensation according to the loading situation.

n   BACKGAUGE

Accurate backgauge's backwards and forwards motion is controlled by X axis, the imported ball screw and liner guide rail are used with high precision, high-rigidity, fast-speed, strong-carrying capability.

ü  OPTIONAL COMPONENTS

1.         SECTION PUNCH AND DIES –PLEASE PROVIDE US THE DIMENSION IF NEEDED

2.         FAST RELEASED CLAMP---USD600/SET MACHINE,WE HAVE INCLUDED THIS INTO THE PRICE.

3.         BALL SCREW BACKGAUGE FINGERS---USD250/SET MACHINE INCLUDED ALREADY.

4.         EUROPAN SNGILE V DESIGN IS POSSIBLE, SINGLE V IS OPPOSITE TO THE MULTI V (YOU CAN CHECK OUT MULTI V AT THE STANDRAD PUNCH AND DIES ARTICLE BELOW. MULTI V MEANS HAS SEVEARL V IN DIFFERENT SIDE) SINGLE V IS POPULAR IN EUROPEAN ,BUT SHOULD CALCULATE THE THICKNESS FIRSTLY FOR THE METAL PLATE TO MADE A DECISION. NORMALLY MULTI V IS BETTER IN USAGE TO SETTLE DIFFERENT THICKNESS PLATE BENDING SOLUTION.

5.         MOTOR-CRWONG (V COMPENSATION AXIS ) IS INCLUDED. IF NOT NEEDED,PLEASE LET US KNOW ALSO. WE RECOMMEND TO USE. WE WILL EXPLAIN V AXIS COMPENSATION BELOW.

6.         LASER LIGHT SECURITY PROTECTOIN IF NEEDED

ü  DELEM DNC 60 SYSTEM

1.         DELEM DA52 CAN CONTROL Y1/Y2/X+V AXIS 3+1 AXIS

2.         THE CONTROL ELECTRONIC-HYDRAULIC SYNCHRONIZATION

7.         THROUGH GRATING RULER AND THE SERVO MOTOR TO GET THE SINGEL WITH THE TWO CYLINDER

8.         HAS THE ANGLE BENDING FUNCTION, THE Y/X/R+V AXIS CAN AUTOMATICALLY CALCULATED BY SET INTO THE ANGLE NEEDED

9.         SET INTO THE SYSTEM PUNCH,DIES,STROKE SPECIFAICATION ,ALL THE OTHER STEPS WILL BE CALCULATED DIRECTLY

10.       CAN CALCULATE STAINLESS STEEL,CARBON STEEL ,ALUMIIUM ITSELF

11.       POSSIBLE TO MAKE ANGLE CORRECTION FUNCTION

12.       CAN USE USB TO PUT INTO THE DRAWED CAD ,THE MACHINE SYSTEM CAN READ AND WORK DIRECTLY.

13.       WORLDWIDE POPULAR CONTROL SYSTEM

14.       OPERATION MANUAL IS AVAILABE

15.       ELECTRONIC DRAWING IS AVAILABE

16.       HYDRAULIC SYSTEM DRAWING IS AVIABLE

17.       WE CAN DEPATCH OUR ENGINEER FROM UK TO TRAIN YOU IF NEEDE,THE SALARY WILL BE PAID BY BUYER.

Whether the machine price can be more discount

Durmapress always provide high quality machine,as we know ,oversea market is more important and difficult than domestic market because of communication time costing after sales,So always,our machine has enough qaulity standard to make sure the machine can work more than the real warranty period.In this way ,we will save a lot and think in advance for the clients.
Actually Durmapress also think about our price level,we are sure to provide quality=price and pice=quality ,the matched price and acceptable for the clients and durable for our machines.We welcome your negotiate with us and get a good satisfaction.

 How about your manufactory in CHINA

Durmapress located in MAANSHAN CITY ,ANHUI PROVINCE province who is the leading area in China and also in the worldwide as the center of the metal plate solution machines,We have worked about 10 years in this area and totally have about 150 staffs.Rich experience in this field with professional technical supporting and oriented service.
We welcome your visit to us any time.
