6mm hydraulic sheet iron plate shearing machine

Price: 7600.0 USD
Payment Terms: T/T,L/C,WU,Paypal
Place of Origin: Anhui, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: QC12Y-6x2500
Production Capacity: 30 sets per month for the s...
Delivery Date: 4weeks for sheet metal cutt...
Raw Material: Sheet / Plate Rolling
Extra Services: Cut To Length
Certification: CE
Brand Name: Durmapress
Cutting thickness: 6mm
Name: Hydraulic shearing machine
Cutting material: Metal sheet , stainless ste...
Weight: 6Ton
Cutting stainless steel thickness: 3mm
Means of Transport: Ocean,Land
Packing: Inner with waterproof film,...
Power: Hydraulic
Machine Type: Others
Automation: Automatic
Material / Metal Processed: Stainless Steel
cutting width: 2500mm
control system: E21s
Voltage: 380V also can according to ...
Rate power: 7.5KW
Warranty: 2 YEARS

6mm metal sheet shearing machine
2500mm metal sheet cutting machine
swing beam shearing machine
QC12Y swing beam shearing machine
2.5m shearing

General descriptions:

1. The design style is as per Germany Standard DIN55222T2-80
2. The frame is steel welded construction, vibration to eliminate stress, with high strength and good rigidity
3. Adopting rolling guiding way with three point support to make sure good cutting quality and accuracy
4. The back gauge is adjusted by motor and fine adjusted by hand wheel. The strokes is shown by autonics digital displayer and can be adjusted stepless.
5. The gap between upper and bottom blades can be adjusted by hand wheel.
6. Rectangular blades have four cutting edges and have long service life.
Own advantage:
Hydraulic system:
1. First valve (from U. S. A) make sure good working, long service life and low noise.
2. NOK oil seal (from Japan) prevents oil leaking with long service life
3. Sleeve type pipe joint to make sure there is no oil leaking
4. Best quality pump provide long service life and low noise
Electric system:
1. Schneider or simense electric parts with good quality and easy to replace around the world
2. Autonics digital displayer (from Korea) has good accuracy and long life
3. Autonics encoder (from Korea) has good accuracy and long life
4. Best quality motor provide enough power and low noise.

Model
QC11Y

Max Shearing
Thickness (mm)

Max Shearing
Width (mm)

Shearing
Angle   (° )

Throat
Depth (mm)

Max Distance of
Back-gauge (mm)

Main Motor
Power (kw)

Dimension
 (mm)

6x2500

6

2500

0.5-1.5

80

750

7.5

3000x2075x1920

6x3200

6

3200

0.5-1.5

80

750

7.5

3130x2075x1970

6x4000

6

4000

0.5-1.5

80

750

7.5

4530x2075x2000

6x5000

6

5000

0.5-1.5

80

750

7.5

6430x2075x2520

6x6000

6

6000

0.5-1.5

80

750

7.5

7530x2075x2210

7x7000

7

7000

0.5-1.5

80

750

7.5

7530x2075x2600

8x2500

8

2500

0.5-1.5

80

750

7.5

3040x2075x1920

8x3200

89

3200

0.5-1.5

80

750

7.5

3740x2075x1920

12x2500

12

2500

0.5-2

80

1000

15

3110x2575x2210

12x3200

12

3200

0.5-2

80

1000

15

3810x2575x2500

12x4000

12

4000

0.5-2

80

1000

15

4610x2575x2500

16x2500

16

2500

0.5-2.6

80

1000

22

3130x2655x2200

16x4000

16

4000

0.5-5.5

80

1000

20

4430x2655x2570

20x2500

20

2500

0.5-2.6

80

1000

20

3100x2600x2300

20x4000

20

4000

0.5-5.5

80

1000

30

4600x2055x2720

25x3200

25

3200

0.5-3.5

80

1000

37

3610x2000x3300



Company Information

1. Company name: Maanshan Durmapress Machinery Technology Co.,ltd
2. Machine Brand: Durmapress
3. Durmapress is leading manufacturer: bending machine, press brake, shearing machine, rolling machine and press machine
4. Official website: cndurma.com
5. Address: Bowang Industril Park,  Ma'anShan Anhui China

Maanshan Durmapress Machinery Technology Co.,ltd is located  in National spark technology compact district-Bowang Industry area (aide the province NO.314 Highway), only 26 Kilometers far from Nanjing Lukou International Airport. The company occupies more than 25,000 square meters, register funds 16 million Yuan. There are more than 200 workers, among them 26 different kinds of engineers.

Our products are widely used in decoration, matallurgical, ship, car, machinery, aviation and other professional area. The company has a strong technical team to meet customer's specific requirements.

The company will always remember ''first-class enterprise, first-class brand, first-class image'' goals. And we hope to create a brilliant career with the friends home and abroad.


Technical Data



Model QC12K-6*2500
Cutting thickness6mm
cutting length2500mm
cutting angle 1.5°
Throat depth100mm
Back-gauge Range20-600mm
Travel times15 cycle/min
Power7.5kw
Dimension(L*W*H)3000*1650*1800mm
Weight5800kg
Oil pump16MCY-14

 Note: we supply series model shearing machine, welcome to inquiry.
